| 規格 | GHD-14A 自動進刀鉆床 | |
| 最大鉆孔能力 | 鉆孔 Φ16 | |
| 軸心行程 | 93mm | |
| 馬力 | 1HP4P | |
| 轉速變換數 | 4 | |
| 轉速 | 50HZ | 466-1675 |
| 60HZ | 560-2010 | |
| 主軸型式 | 主軸斜度 | MT2# |
| 鼻端斜度 | JT2 1/2# | |
| 重量 | 102KG | |
| Specification | GHD-14A Auto-feed drilling machine | |
| Max.capacity | DrillingΦ16 | |
| Spindie stroke | 93mm | |
| Horsepower | 1HP4P | |
| Speed variation | 4 | |
| Rotation speed | 50HZ | 466-1675 |
| 60HZ | 560-2010 | |
| Spindle trye | Spindle tape | MT2# |
| Spindle nose | JT2 1/2# | |
| Weight | 102KG | |
